MẠCH CHÍNH VI TÍNH GIGABYTE H510M H V2

Thương hiệu: Gigabyte
Mã sản phẩm: ABGI_H510M_H_V2
Tình trạng: Còn hàng
Bảo hành: 36 tháng
1.580.000 ₫

(Đã bao gồm VAT)

1.630.000 ₫ - 3.07%
MUA NGAY
THÊM VÀO GIỎ HÀNG
CHÍNH SÁCH MUA HÀNG

MẠCH CHÍNH VI TÍNH GIGABYTE H510M H V2

Một trong những điểm mạnh nổi bật của Bo Mạch Chủ H510M-H V2  là hiệu năng vượt trội và tính ổn định cao. Với việc sử dụng công nghệ tiên tiến và linh kiện chất lượng, bo mạch chủ này giúp máy tính của bạn hoạt động mượt mà và ổn định trong mọi tình huống, từ công việc văn phòng đơn giản đến các trò chơi và ứng dụng nặng nề.

Đến từ nhà sản xuất GIGABYTE, mainboard GIGABYTE H510M-H V2  được tin dùng với thiết kế kích thước chuẩn mainboard Micro-ATX được sử dụng rộng rãi, tương thích với đa dạng thiết bị, giúp việc lắp đặt hay tìm kiếm thay thế dễ dàng hơn.

 Kích thước chuẩn mainboard Micro-ATX

Bên cạnh đó, GIGABYTE H510M-H được trang bị chipset H510 và socket 1200 hỗ trợ nhiều dòng CPU hơn, sử dụng lâu bền hơn, đem lại hiệu năng cực khủng, tốc độ nhanh chóng bất ngờ.

 Hỗ trợ nhiều dòng CPU

Được nâng cấp hơn so với nhiều dòng sản phẩm cũ, mainboard GIGABYTE cung cấp năng lượng sạch hơn, hiệu quả hơn cho CPU, đem lại hiệu suất nhiệt tốt, đảm bảo hoạt động ổn định trong trường hợp công việc tần số cao và nặng.

RAM DDR4

Đặc biệt, mainboard GIGABYTE H510M-H có 2 khe RAM DDR4 hỗ trợ tối đa 64 GB, tạo ra không gian lưu trữ rộng lớn, cho phép thiết bị thực hiện đa tác vụ dễ dàng, tải các ứng dụng, phần mềm mà không lo quá tải.

Mainboard Gigabyte H510M H V2

Hơn thế nữa, bo mạch chủ H510M-H có nhiều cổng lưu trữ như SATA 3, M.2 SATA/NVMe và các khe PCI đem lại khả năng giao tiếp hiện đại, quá trình truyền tải và xử lý dữ liệu với khối lượng lớn, tốc độ cao và kết quả chính xác.

Cổng lưu trữ đa dạng

Ngoài ra, mainboard GIGABYTE sử dụng cổng xuất hình HDMI và VGA/D-sub giúp kết nối đa dạng thiết bị, khả năng phù hợp tuyệt đối, đem lại chất lượng xuất ra nguyên bản và ít rủi ro nhất.

Thông sốGiá trị
Hãng sản xuấtGIGABYTE
Loại sản phẩmMAINBOARD
ChipsetIntel® H470 Express Chipset
SocketLGA1200 package:
11th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors
10th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors / Intel® Core™ i3 processors/ Intel® Pentium® processors / Intel® Celeron® processors
L3 cache varies with CPU
Khe RAM tối đa2
Kiểu RAM hỗ trợDDR4
Dung lượng RAM tối đa64GB
Tốc độ buss Ram11th Generation Intel® Core™ i9/i7/i5 processors:
Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules
10th Generation Intel® Core™ i9/i7 processors:
Support for DDR4 2933/2666/2400/2133 MHz memory modules
10th Generation Intel® Core™ i5/i3/Pentium®/Celeron® processors:
Support for DDR4 2666/2400/2133 MHz memory modules
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
Ổ cứng hỗ trợChipset:
1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 3.0 x4/x2 SSD support)
4 x SATA 6Gb/s connectors
RAID 0, RAID 1, RAID5, and RAID 10 support for NVMe SSD storage devices
* Supported with an additional PCIe to M.2 NVMe SSD adapter card
RAID 0, RAID 1, RAID5, and RAID 10 support for SATA storage devices
Cổng xuất hình1 x HDMI port
1 x D-Sub port
Khe PCICPU:
1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16
Chipset:
1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
USB4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
Cổng kết nối bên trong1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
1 x system fan header
1 x RGB LED strip header
1 x M.2 Socket 3 connector
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x serial port header
1 x Clear CMOS jumper
Cổng I/O phía sau1 x PS/2 keyboard/mouse port
1 x D-Sub port
1 x HDMI port
2 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks
LANRealtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
Âm thanhRealtek® Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
Đồ họaIntegrated Graphics Processor-Intel® HD Graphics support:
1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
* Support for HDMI 1.4 version and HDCP 2.3.
1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
* The D-Sub port is only available with the 10th Generation processors.
(Graphics specifications may vary depending on CPU support.)
Operating System SupportSupport for Windows 11 64-bit
Support for Windows 10 64-bit
BIOS1 x 128 Mbit flash, AMI UEFI BIOS
Kích thướcMicro ATX; 23.0cm x 19.8cm
Bảo hành36 tháng
