| Thông số | Giá trị |
|---|---|
| Hãng sản xuất | ASUS |
| Loại sản phẩm | MAINBOARD |
| Hệ điều hành | Windows® 10 64-bit |
| Chipset | Intel® B365 |
| Socket | Intel® Socket 1151 9th / 8th Gen Intel® Core™, Pentium® Gold and Celeron® Processors Supports Intel® 14 nm CPU Supports Intel® Turbo Boost Technology 2.0 |
| Khe RAM tối đa | 2 |
| Kiểu RAM hỗ trợ | DDR4 |
| Dung lượng RAM tối đa | 32GB |
| Tốc độ buss Ram | DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) |
| Ổ cứng hỗ trợ | Intel® B365 Chipset : 1 x M.2 Socket 3, , with M Key, type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode) 6 x SATA 6Gb/s port(s), gray, Support Raid 0, 1, 5, 10 Intel® Optane™ Memory Ready |
| Lưu trữ | 1 x M.2 Socket 3, , with M Key, type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode)*1 6 x SATA 6Gb/s port(s), gray, Support Raid 0, 1, 5, 10 Intel® Optane™ Memory Ready |
| Cổng xuất hình | 1 x DVI-D 1 x D-Sub |
| Khe PCI | 1 x PCIe 3.0/2.0 x16 (x16 mode, gray) 2 x PCIe 3.0/2.0 x1 |
| USB | 6 x USB 3.1 Gen 1 up to 5Gbps port(s) (4 at back panel, blue, Type-A, 2 at mid-board) 6 x USB 2.0/1.1 port(s) (2 at back panel, black, 4 at mid-board) |
| Cổng kết nối bên trong | 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode) 1 x COM port(s) connector(s) 6 x SATA 6Gb/s connector(s) 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x Chassis Fan connector(s) (1 x 4 -pin) 1 x S/PDIF out header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin EATX 12V Power connectors 1 x Front panel audio connector(s) (AAFP) 1 x Clear CMOS jumper(s) 1 x System panel connector 1 x Speaker connector |
| Cổng I/O phía sau | 1 x PS/2 keyboard (purple) 1 x PS/2 mouse (green) 1 x DVI-D 1 x D-Sub 1 x LAN (RJ45) port(s) 4 x USB 3.1 Gen 1 (blue) Type-A up to 5Gbps 2 x USB 2.0 1 x 8-channel Audio I/O |
| LAN | Realtek® RTL8111H, 1 x Gigabit LAN ASUS LAN Guard |
| Âm thanh | Realtek® ALC887 8-Channel High Definition Audio CODEC - Supports : Jack-detection, Front Panel Jack-retasking |
| Đồ họa | Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support: DVI-D/D-Sub ports - Supports DVI-D with max. resolution 1920 x 1200 @60Hz - Supports D-sub with max. resolution 1920 x 1200 @60Hz Maximum shared memory of 1024 MB (for iGPU exclusively) Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™ |
| Operating System Support | Windows® 10 64-bit |
| BIOS | UEFI AMI BIOS |
| Kích thước | mATX Form Factor 8.9 inch x 7.3 inch ( 22.6 cm x 18.5 cm ) |
| Bảo hành | 36 tháng |
